产品代码 : ME-Zr-5N-WI
Zirconium wire has a silvery metallic appearance and is produced by drawing metal zirconium wire. Zirconium wire has a high melting point up to 1855°C and a small neutron adsorption cross section, making it ideal for use in the nuclear power industry. Zirconium wire is also commonly used in aerospace, chemical, refractory, ceramics and other industries.
CAS #: 7440-67-7
Linear Formula: Zr
MDL Number: MFCD00011303
EC No.: 231-176-9
如果您需要定制服务，请联系我们。 我们将在 24 小时内与您联系并告知价格和可用性。
| 产品 | 产品代码 | 纯度 | 尺寸 | 联系我们 |
Product Information
Zirconium wire has a silvery metallic appearance and is produced by drawing metal zirconium wire. Zirconium wire has a high melting point up to 1855°C and a small neutron adsorption cross section, making it ideal for use in the nuclear power industry. Zirconium wire is also commonly used in aerospace, chemical, refractory, ceramics and other industries.
Synonyms
GF11910743, GF22277527, GF49034022, GF98267417, GF34962082, 00416, 00419, 00939, 10588, 14627, 43334, 45056
Specifications Of Zirconium Wire
| Dimensions | Dia.: 0.5–6mm |
| Material | R60702 |
| Standard | ASTM B550 |
| Purity | ≥99% |
ATT can design and manufacture according to customer's requirements beyond the regular dimension.
Chemical Composition of Zirconium Wire
| Grades | Main component | Impurity content(wt% ≤) | |||||||
| Zr+Hf | Hf | Fe+Cr | Sn | Nb | C | N | O | H | |
| R60700 | 99.2 | 4.5 | 0.2 | - | - | 0.05 | 0.025 | 0.10 | 0.005 |
| R60702 | 99.2 | 4.5 | 0.2 | - | - | 0.05 | 0.025 | 0.16 | 0.005 |
Zirconium Wire Properties
| Molecular Weight | 91.22 |
| Appearance | Gray to black powder |
| Melting Point | 1852 °C |
| Boiling Point | 3580 °C |
| Density | 6506 kg/m3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 40.0 microhm-cm @ 20 oC °C |
| Electronegativity | 1.4 Paulings |
| Heat of Fusion | 5.50 Cal/gm mole |
| Heat of Vaporization | 120 K-Cal/gm atom at 4377 °C |
| Poisson's Ratio | 0.34 |
| Specific Heat | 0.0671 Cal/g/K @ 25 oC °C |
| Tensile Strength | 230 MPa |
| Thermal Conductivity | 0.227 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 5.7 µm·m-1·K-1 |
| Vickers Hardness | 903 MPa |
| Young's Modulus | 88 GPa |
Applications of Zirconium Wire
Zirconium wire is mainly used in aerospace, chemical industry, refractory materials, ceramics and other industries.
Packaging of Zirconium Wire
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’Zirconium Wire is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Zr |
| MDL Number | MFCD00011303 |
| EC No. | 231-176-9 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23995 |
| SMILES | [Zr] |
| InchI Identifier | InChI=1S/Zr |
| InchI Key | QCWXUUIWCKQGHC-UHFFFAOYSA-N |
