产品代码 : ME-Zr-5N-SP
Zirconium has been used to make electrodes components, foils, flanges bolts, tubes and rods for special applications. Zirconium products also have wide applications in medical equipment, such as zirconium implants. As Zirconium sheets/plates have better mechanical strength under high temperature, it is also used as support and structure components for high-temperature applications.
如果您需要定制服务，请联系我们。 我们将在 24 小时内与您联系并告知价格和可用性。
| 产品 | 产品代码 | 纯度 | 尺寸 | 联系我们 |
Product Information
Zirconium is a very strong, malleable, ductile, lustrous silver-gray metal, similar to hafnium and titanium. It is flammable in powder form, and highly resistant to corrosion and heat. Zirconium is a high corrosion-resistant metal that is us used for many products. Some include pumps, valves, nuclear applications, chemical processing, reactor vessels, heat exchangers and more.
Zirconium has been used to make electrodes components, foils, flanges bolts, tubes and rods for special applications. Zirconium products also have wide applications in medical equipment, such as zirconium implants. As Zirconium sheets have better mechanical strength under high temperature, it is also used as support and structure components for high-temperature applications.
Synonyms
00934, 10593, 44261
Specifications Of Zirconium Sheet & Zirconium plate
| Item Name | Zirconium Sheet / Zirconium plate |
| Material | R60702, R60705 |
| Size | 0.3mm-50mm T x 100-1000mm W x 100-2000mm L |
| Specification | ASTM B551/551M-07 |
| Surface | Pickled, Sandblasted, Shiny |
Availability of pure Zirconium Sheet & Zirconium Plate
| .002″ x 6″ x 12″ | .040″ x 12″ x 24″ | .500″ x 12″ x 24″ |
| .004″ x 12″ x 24″ | .050″ x 12″ x 24″ | .625″ x 12″ x 24″ |
| .005″ x 12″ x 24″ | .060″ x 12″ x 24″ | .750″ x 12″ x 24″ |
| .010″ x 12″ x 24″ | .080″ x 12″ x 24″ | 1.00″ x 12″ x 24″ |
| .015″ x 12″ x 24″ | .125″ x 12″ x 24″ | 1.50″ x 12″ x 24″ |
| .020″ x 12″ x 24″ | .188″ x 12″ x 24″ | 2.00″ x 12″ x 24″ |
| .025″ x 12″ x 24″ | .250″ x 12″ x 24″ | 2.50″ x 12″ x 24″ |
| .030″ x 12″ x 24″ | .375″ x 12″ x 24″ | 3.00″ x 12″ x 24″ |
We Offer Competitive Pricing And Great Lead Times On All Our Materials, And We're Capable Of Supplying Custom Materials Per Any Specs/Drawings You Provide Us With.
Chemical composition for Zirconium Sheet & Zirconium Plate
| Grade | Zr+Hf | Hf | Fe+Cr | Sn | H | N | C | O | Nb |
| R60702 | 99.2% | <4> | <0> | – | <0> | <0> | <0> | <0> | – |
| R60704 | 97.5% | <4> | 0.2-0.4% | 1.0-2.0% | <0> | <0> | <0> | <0> | – |
| R60705 | 95.5% | <4> | <0> | – | <0> | <0> | <0> | <0> | 2.0-3.0% |
Applications Of Zirconium Sheet & Zirconium Plate
* Used To Make High-Temperature Superconductive Materials.
* Used to make electrodes components, foils, flanges bolts, tubes and rods for special applications.
* Used for applications in medical equipment, such as zirconium implants.
* As Zirconium sheets have better mechanical strength under high temperature, it is also used as support and structure components for high-temperature applications
Packaging Of Zirconium Sheet & Zirconium Plate
Standard Packing:
Sealed bags in carton boxes. Special package is available on request.
ATTs’ Zirconium Sheet/Plate is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Zr |
| CAS | 7440-67-7 |
| MDL Number | MFCD00011303 |
| EC No. | 231-176-9 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23995 |
| SMILES | [Zr] |
| InchI Identifier | InChI=1S/Zr |
| InchI Key | QCWXUUIWCKQGHC-UHFFFAOYSA-N |
