产品代码 : EM-Ti2O3-5N-Cu
Titanium trioxide (Ti2O3) is an evaporative material that is used for numerous thin-film processes. It is suitable for a wide range of semiconductor, industrial, decorative, and metalizing applications. The most common uses for this material are for metalizing (coating), optical coatings, semiconductors, and as a high-temperature adhesive (glue). It is also used as a pigment in paints and plastic products. It is commonly produced by chemical vapor deposition (CVD) and has excellent electrical, mechanical and optical properties. The primary benefit of this material is its ability to be used as an optically transparent coating.
如果您需要定制服务，请联系我们。 我们将在 24 小时内与您联系并告知价格和可用性。
| 产品 | 产品代码 | 纯度 | 尺寸 | 联系我们 |
Product Information
Titanium trioxide (Ti2O3) is an evaporative material that is used for numerous thin-film processes. It is suitable for a wide range of semiconductor, industrial, decorative, and metalizing applications. The most common uses for this material are for metalizing (coating), optical coatings, semiconductors, and as a high-temperature adhesive (glue). It is also used as a pigment in paints and plastic products. It is commonly produced by chemical vapor deposition (CVD) and has excellent electrical, mechanical and optical properties. The primary benefit of this material is its ability to be used as an optically transparent coating.
Material Type: Titanium trioxide
Symbol: Ti2O3
Titanium Trioxide (Ti2O3) Evaporation Material Specification
Size：Pellet / Wire / Rod / Slug / Tablet / Customized
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Compound Formula | Ti2O3 |
| Molecular Weight | 143.73 g/mol |
| Appearance | violet black powder |
| Melting Point | 2,130° C (3,866° F) |
| Boiling Point | N/A |
| Density | 4.49 g/cm3 |
| Solubility in H2O | N/A |
| Exact Mass | 143.880636 |
| Monoisotopic Mass | 143.880636 |
Application of Titanium Trioxide (Ti2O3) Evaporation Material
• Used in deposition processes including semiconductor deposition, chemical vapor deposition (CVD) and physical vapor deposition (PVD)
• Used for optics including wear protection, decorative coatings, and displays.
Packing of Titanium Trioxide (Ti2O3) Evaporation Material
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request. They are vacuum sealed. The MSDS and Material Certification Sheets will be packed with the product.
ATTs’Titanium Trioxide (Ti2O3) Evaporation Material is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Ti2O3 |
| MDL Number | MFCD00036278 |
| EC No. | 215-697-9 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 123111 |
| IUPAC Name | oxo(oxotitaniooxy)titanium |
| SMILES | O=[Ti]O[Ti]=O |
| InchI Identifier | InChI=1S/3O.Ti |
| InchI Key | GQUJEMVIKWQAEH-UHFFFAOYSA-N |
