产品代码 : EM-Ca-5N-Cu
High purity Calcium evaporation materials play a huge role in deposition processes to ensure high quality deposited film. ATT specializes in producing up to 99.5% purity calcium evaporating materials using quality assurance processes to guarantee product reliability.
Calcium has a density of 1.54 g/cc, a melting point of 839°C, and a vapor pressure of 10-4 Torr at 459°C. Calcium is an essential building block for human life as it is found in abundance in human skeletons and teeth.
如果您需要定制服务，请联系我们。 我们将在 24 小时内与您联系并告知价格和可用性。
| 产品 | 产品代码 | 纯度 | 尺寸 | 联系我们 |
Product Information
High purity Calcium evaporation materials play a huge role in deposition processes to ensure high quality deposited film. ATT specializes in producing up to 99.5% purity calcium evaporating materials using quality assurance processes to guarantee product reliability.
Calcium has a density of 1.54 g/cc, a melting point of 839°C, and a vapor pressure of 10-4 Torr at 459°C. Calcium is an essential building block for human life as it is found in abundance in human skeletons and teeth.
ATT provides high-quality Calcium (Ca) Evaporation Materials for research and industry purposes at competitive prices. We can provide Calcium (Ca) Evaporation Materials with different purity, size, and density according to your requirements.
Material Type：Calcium
Symbol：Ca
Color/Appearance： Silvery White, Metallic
Synonyms
N/A
Calcium (Ca) Evaporation Materials Specification
Size：Pellet / Wire / Rod / Slug / Tablet / Customized
Per your request or drawing
We can customized as required
Properties（Theoretical）
| Molecular Weight | 40.07 |
| Appearance | Silvery |
| Melting Point | 839 °C |
| Boiling Point | 1484 °C |
| Density | 1.55 g/cm3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 3.91 microhm-cm @ 0 °C |
| Electronegativity | 1.0 Paulings |
| Heat of Fusion | 2.23 Cal/gm mole |
| Heat of Vaporization | 36.74 K-Cal/gm atom at 2467 °C |
| Poisson's Ratio | 0.31 |
| Specific Heat | 0.156 Cal/g/K @ 25 °C |
| Tensile Strength | N/A |
| Thermal Conductivity | 2.01 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 22.3 µm·m-1·K-1 |
| Vickers Hardness | N/A |
| Young's Modulus | 20 GPa |
Application of Calcium (Ca) Evaporation Materials
• Used in deposition processes including semiconductor deposition, chemical vapor deposition (CVD) and physical vapor deposition (PVD)
• Used for optics including wear protection, decorative coatings, and displays.
Packing of Calcium (Ca) Evaporation Materials
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request. They are vacuum sealed. The MSDS and Material Certification Sheets will be packed with the product.
ATTs’Calcium (Ca) Evaporation Materials is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Ca |
| MDL Number | MFCD00085314 |
| EC No. | 231-179-5 |
| Beilstein/Reaxys No. | 4241647 |
| Pubchem CID | 5460341 |
| SMILES | [Ca] |
| InchI Identifier | InChI=1S/Ca |
| InchI Key | OYPRJOBELJOOCE-UHFFFAOYSA-N |
