产品代码 : 3D-TiGrade1-CU-PO1
Grade 1 Spherical Titanium (Ti) Powder is a pure titanium material, which has good mechanical properties and biocompatibility but also has excellent corrosion resistance. Pure titanium parts have a wide application prospect in the chemical industry, ship, medical treatment, and other fields. Grade1 is suitable for selective laser melting(SLM) forming.
如果您需要定制服务，请联系我们。 我们将在 24 小时内与您联系并告知价格和可用性。
| 产品 | 产品代码 | 纯度 | 尺寸 | 联系我们 |
Spherical Titanium (Ti) Powder Synonyms
Titanium particles, Titanium microparticles, Titanium micropowder, Titanium micro powder, Titanium micron powder, Titanium submicron powder, Titanium sub-micron powder.
Spherical Titanium (Ti) Powder Chemical Composition
| Grade | Al | V | Fe | C | N | H | O |
| TC4 | 5.5~6.75 | 3.5~4.5 | ≤0.30 | ≤0.08 | ≤0.05 | ≤0.015 | 0.08~0.15 |
| TC4ELI | 5.5~6.5 | 3.5~4.5 | ≤0.25 | ≤0.08 | ≤0.03 | ≤0.012 | 0.08~0.13 |
| Element, Mass Fraction(Wt.%) | |||||||
| Grade | Chemical Composition (wt.%) | |||||||||||
| Ti | Fe | Al | V | C | N | H | O | Si | Zr | Mo | Cr | |
| Commerciallly Pure Titanium | Bal. | ≤0.10 | ≤0.08 | ≤0.03 | ≤0.015 | ≤0.15 | ≤0.08 | |||||
| Ti6Al4V | Bal. | ≤0.30 | 5.50-6.75 | 3.50-4.50 | ≤0.08 | ≤0.03 | ≤0.015 | ≤0.12 | ||||
| TA15/BT20 | Bal. | ≤0.25 | 5.50-7.10 | 0.80-2.5 | ≤0.08 | ≤0.05 | ≤0.015 | ≤0.15 | ≤0.15 | 1.5-2.5 | 0.50-2.0 | |
| TC11/BT9 | Bal. | ≤0.25 | 5.80-7.00 | ≤0.08 | ≤0.05 | ≤0.01 | ≤0.15 | 0.20-0.35 | 0.80-2.00 | 2.80-3.80 | ||
| TC18 | Bal. | 0.5-1.5 | 4.4-5.7 | 4.0-5.5 | ≤0.08 | ≤0.05 | ≤0.015 | ≤0.18 | ≤0.15 | ≤0.30 | 4.0-5.5.5 | 0.5-1.5 |
Spherical Titanium (Ti) Powder Particle Size Description
● 0-15μm (D10=3~5μm, D50=6~10μm, D90=12~14μm)
● 5-25μm (D10=5~10μm, D50=15~20μm, D90=20~25μm)
● 15-45μm (D10=15~20μm, D50=25~30μm, D90=35~40μm)
● 15-53μm (D10=15~20μm, D50=25~35μm, D90=45~50μm)
● 45-75μm (D10=45~55μm, D50=55~65μm, D90=70~75μm)
● 45-105μm (D10=50~60μm, D50=75~85μm, D90=95~105μm)
● 45-150μm (D10=55~70μm, D50=110~120μm, D90=140~150μm)
● 75-150μm (D10=80~90μm, D50=110~125μm, D90=135~150μm)
Spherical Titanium (Ti) Powder Particle Size
0-15μm, 5-25μm, 15-45μm, 15-53μm, 45-75μm, 45-105μm, 75-150μm, 105-250μm. (Various granularities can be customized according to customer requirements)
Spherical Titanium (Ti) Powder Applicable Process
Laser/electron beam additive manufacturing (SLM/EBM), laser direct deposition (DLD), powder hot isostatic pressing (HIP), metal injection molding (MIM), powder metallurgy (PM), laser cladding (LC), and other processes.
Spherical Titanium (Ti) Powder Application
Pure titanium parts have a wide application prospect in the chemical industry, ship, medical treatment, and other fields. Grade1 is suitable for selective laser melting (SLM) forming.
Packing of Spherical Titanium (Ti) Powder
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’Spherical Titanium (Ti) Powder is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Ti |
| MDL Number | MFCD00011264 |
| EC No. | 231-142-3 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23963 |
| SMILES | [Ti] |
| InchI Identifier | InChI=1S/Ti |
| InchI Key | RTAQQCXQSZGOHL-UHFFFAOYSA-N |
